UP200Ht – Handheld Ultrasonic Homogenizer
SKU : UP200Ht
฿0
Quantity
Short Description
The UP200Ht (200W, 26kHz) handheld homogenizer is part of the digital device series of Hielscher’s 200 watt ultrasonic homogenizers which come with broad range of new accessories. The new features include digital control and touch screen, automatic data recording, intuitive operation and ergonomic and shapely design for the most user-friendly use and working comfort.
Read more: https://www.hielscher.com/200ht_p.htm
Brands: Hielscher Ultrasonics
Product description
The device functions and the various accessories allow for different applications and the coverage of very wide parameter configurations. Typical applications of this powerful sonicator are homogenization, dispersing, emulsification, disintegration, cell disruption, degassing or sonochemistry. Hielscher designed this state-of-the-art 200W portable homogenizer to give the user a high flexibility, ease of use and a new level of accuracy and control.
In comparison with its predecessors UP200H and UP200S, the new ultrasonic device UP200Ht features many additional functions and very smart user friendliness. With its 200 watts power the UP200Ht offers the same performance and reliability as UP200H and UP200S, but it differs by its completely new design that is more comfortable for the handheld and stand-mounted use. Due to the broad coverage of parameter configurations (by variation of amplitude, pressure, temperature, flow cell, glass sonotrode,…), the UP200Ht covers the full range of applications, such as homogenization, emulsification, dispersion, disintegration, cell disruption & extraction, degassing as well as sono-chemical and sono-catalytical processes – for small and medium size volumes.
Generally, the UP200Ht is used for the sonication of sample volumes from 0.1 to 1000mL. Hielscher offers various sonotrodes from 1 to 40mm tip diameter. Whilst the 40mm sonotrode transmits the ultrasound smoothly across a relatively large surface, the sonotrodes with smaller tip diameter operate at higher amplitudes and at higher intensities, e.g. for destructive applications. The UP200Ht can be also used for the production of smaller quantities, mostly in continuous flow with the use of flow cells and the appropriate sonotrodes. In combination with the flow cell FC7K, the material can be sonicated in a continuous flow-through mode, e.g. at a flow rate of 20 to 200mL per minute. The stainless steel flow cell is pressurizable up to 5 barg. By this, continuous sonication processes can be simulated in smallest scale. Due to its reliability and IP41 grade, the UP200Ht can be operated 24 hours per day (24h/7d), allowing for the processing of up to 180L per day (depending on the application).
Read more: https://www.hielscher.com/200ht_p.htm
In comparison with its predecessors UP200H and UP200S, the new ultrasonic device UP200Ht features many additional functions and very smart user friendliness. With its 200 watts power the UP200Ht offers the same performance and reliability as UP200H and UP200S, but it differs by its completely new design that is more comfortable for the handheld and stand-mounted use. Due to the broad coverage of parameter configurations (by variation of amplitude, pressure, temperature, flow cell, glass sonotrode,…), the UP200Ht covers the full range of applications, such as homogenization, emulsification, dispersion, disintegration, cell disruption & extraction, degassing as well as sono-chemical and sono-catalytical processes – for small and medium size volumes.
Generally, the UP200Ht is used for the sonication of sample volumes from 0.1 to 1000mL. Hielscher offers various sonotrodes from 1 to 40mm tip diameter. Whilst the 40mm sonotrode transmits the ultrasound smoothly across a relatively large surface, the sonotrodes with smaller tip diameter operate at higher amplitudes and at higher intensities, e.g. for destructive applications. The UP200Ht can be also used for the production of smaller quantities, mostly in continuous flow with the use of flow cells and the appropriate sonotrodes. In combination with the flow cell FC7K, the material can be sonicated in a continuous flow-through mode, e.g. at a flow rate of 20 to 200mL per minute. The stainless steel flow cell is pressurizable up to 5 barg. By this, continuous sonication processes can be simulated in smallest scale. Due to its reliability and IP41 grade, the UP200Ht can be operated 24 hours per day (24h/7d), allowing for the processing of up to 180L per day (depending on the application).
Read more: https://www.hielscher.com/200ht_p.htm
